【Brand】：
Zhongyang
【Type】：
ZY-900R2-2C-LSR
【Characteristics】：
Classification:
LSR Silicone Machine Series
Keyword:
Zhongyan
Product Details
| MOEDL | UNIT | ZY-1700LSR | ||||
| INJECTION UNIT | Screw Diameter | mm | Ф32 | Ф36 | Ф40 | |
| Theoretical Injection Volume | cm3 | 144.7 | 183 | 226 | ||
| Injection Weight(PS) | g(oz) | 138（4.87） | 175(6.17) | 216（7.6） | ||
| Max.Injection Pressure | Mpa(kgf/cm2) | 229（2331） | 181(1842) | 146(1492) | ||
| Injection Rate | cm3/s | 63.5 | 80.4 | 99 | ||
| Injection Speed | mm/s | 79 | ||||
| Injection Stroke | mm | 180 | ||||
| Screw Speed Rotation | r.p.m | 0-300 | ||||
| NO.of Temperature control | 3 + 1 | |||||
| Nozzle Out From Platens | mm | ≥45 | ||||
| CLAMPING UNIT | Clamping Force | KN(tf) | 1666（170） | |||
| Clamping Stroke | mm | 280 | ||||
| Min.Mold Thickness | mm | 280（380） | ||||
| Max.Opening | mm | 560（660） | ||||
| L*W)Max.Mould Size | mm | 420*420/600*420 | ||||
| （L*W)尺寸Platen Size | mm | Ф120 | ||||
| Ejector Distance | mm | 90 | ||||
| Ejector Force | KN(tf) | 26.5(2.7) | ||||
| System Pressure | Mpa(kgf/cm2) | 13.7(140) | ||||
| OTHERS | Oil Tank Capacity | L | 780 | |||
| Electric Power | KW(HP) | 15(20)+15(20) | ||||
| Machine Dimensions | L*W | m | 2.5*2.4 | |||
| H | m | 3.7 | ||||
| Machine Weight | tf | 9.5 | ||||
Stable in-line screw injection device, secondary injection saturation system, so that the product quality, high precision.
Two-stage temperature control, rate of fire, back pressure, screw speed without adjustment, suitable for all kinds of precision engineering plastic parts molding.
The mold is closed quickly and has a low-pressure safety mold clamping device. Protect the mold.
The lower die is fixed, the upper die is movable, has good positioning for inlaid items, and has a finished product ejection device.
Using high-quality accessories and unique design, the machine has the characteristics of low noise, high efficiency, long life, easy to use, safe operation, and more convenient maintenance.
